Original Part Number: 1-1394453-1
LHE Part Number: 399912411094
Number of Positions: 124
Contact Tab Size Series: Hybrid
Size (MM): L:120 W:120 H:40
Seal or Unseal: Seal
Overview:
| LHE PN: | 399912411094 |
| Certification: | TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS |
| MOQ: | Most product not have MOQ, Small order can be accepted. |
| Sample service: | Free Samples |
| Delivery Time: | 3-5 Days |
| Quality Control | All goods will be 100% inspected before dispatched |
| Payment: | T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. |
| Shipment: | DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving. |
The MOS transistor Q1 is placed on the negative voltage input end of the DC/DC power supply module. At the moment of power-on, the level of the first pin of the DC/DC power supply module is the same as the fourth pin, and then the control circuit reduces it to the negative voltage at a certain rate. , the speed of the voltage drop is determined by the time constant C2*R2, and this slope determines the maximum inrush current. D1 is a Zener diode used to limit the gate-source voltage of the MOS transistor Q1. Components R1, C1 and D2 are used to ensure that the MOS transistor Q1 remains off when it is just powered on.
