Original Part Number: 174966-2
LHE Part Number: 210000421577
Number of Positions: 4
Contact Tab Size Series: 1.0
Size (MM): L:18.7 W:10.9 H:8.1
Seal or Unseal: Unseal
Overview:
| LHE PN: | 210000421577 |
| Certification: | TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS |
| MOQ: | Most product not have MOQ, Small order can be accepted. |
| Sample service: | Free Samples |
| Delivery Time: | 3-5 Days |
| Quality Control | All goods will be 100% inspected before dispatched |
| Payment: | T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. |
| Shipment: | DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving. |
A reflection is an echo on the transmission line. A portion of the signal power (voltage and current) is transmitted to the line and reaches the load, but a portion is reflected as shown in the figure below. The impedance mismatch between the source and the load will cause reflections on the line, and the load will reflect a portion of the voltage back to the source. If the load impedance is less than the source impedance, the reflected voltage is negative, and if the load impedance is greater than the source impedance, the reflected voltage is positive. Variations in trace geometry, incorrect wire termination, transmission through connectors, and discontinuities in power planes can all cause such reflections.
