Process content of starter wire harness and generator wire harness:
● The starter wire harness and engine wire harness are protected by glass fiber tubes
● When the battery compartment and the starter are on the same side of the frame, the starter wiring harness is fixed to the frame beam with a fixed bracket; if it is on the opposite side, it must first transition from the last beam of the frame (or welded round steel) to the other One side is then fixed along the frame girder.
● The generator wiring harness is generally different according to the position of the battery compartment and the generator: when the battery compartment and the generator are on the same side of the starter, the harness is usually fixed on the longitudinal beam of the frame with a bracket; the battery compartment and the generator On the opposite side of the starter, one is that the wiring harness is first fixed along the longitudinal beam and then routed upwards with the support of the intercooler to cross over from the rear of the engine to the generator, and the other is that the wiring harness runs from the last crossbeam of the frame ( Or welded round steel) transition to the other side and then lay along the longitudinal beam or intercooler bracket. In individual cases, fixing brackets of different shapes and sizes can be used to lay on the engine.
The generator wire harness must not be bundled together with the ground wire harness.
