211CC2S1160 Female Unseal PCB Connector Terminal

Original Part Number: 211CC2S1160

LHE Part Number: 6215020053

Contact Tab Size Series: 1.5

Size (MM): L:19.9 W:2.5 H:3.5

Wire Range(mm²): 0.35-0.7

Material: QSN6.5-0.1

Thickness (MM): 0.3

Seal or Unseal: Unseal


LHE PN: 6215020053
Certification: TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS
MOQ: Most product not have MOQ, Small order can be accepted.
Sample service: Free Samples
Delivery Time: 3-5 Days
Quality Control All goods will be 100% inspected before dispatched
Payment: T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery.
Shipment: DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving.
