Original Part Number: 6189-7036
LHE Part Number: 210000210120
Number of Positions: 2
Contact Tab Size Series: 1.0
Size (MM): L:24.5 W:19.3 H:15.4
Seal or Unseal: Seal
Overview:
| LHE PN: | 210000210120 |
| Certification: | TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS |
| MOQ: | Most product not have MOQ, Small order can be accepted. |
| Sample service: | Free Samples |
| Delivery Time: | 3-5 Days |
| Quality Control | All goods will be 100% inspected before dispatched |
| Payment: | T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. |
| Shipment: | DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving. |
Wiring constraints: power supply overcurrent capability (1) The number of vias that are transferred between layers of the power supply conductor printed lines meets the requirements of the passing current (1A/Ф0.3mm hole) (2) The copper foil size of the POWER part of the PCB meets the requirements of the passing current. The maximum current it flows, and the margin is considered (generally referred to as 1A/mm line width)
Wiring constraints: Grounding method: The grounding wire should be short and straight to reduce the distributed inductance and the interference caused by the common ground impedance. Adjust the direction of the filter capacitors in each group to reduce the ground loop. Three filter capacitors, ground biased in the direction of the relevant RF device, especially the high frequency filter capacitors.
