Original Part Number: 6230-5021
LHE Part Number: 263000220854
Number of Positions: 2
Contact Tab Size Series: 6.3
Size (MM): L:25.5 W:13 H:10
Seal or Unseal: Unseal
Overview:
| LHE PN: | 263000220854 |
| Certification: | TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS |
| MOQ: | Most product not have MOQ, Small order can be accepted. |
| Sample service: | Free Samples |
| Delivery Time: | 3-5 Days |
| Quality Control | All goods will be 100% inspected before dispatched |
| Payment: | T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. |
| Shipment: | DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving. |
Smart Power Module Evaluation Board
The evaluation board is a DC/AC inverter that generates waveforms for driving three-phase motors such as induction motors or PMSM motors in HVAC (air conditioners), white goods, and high-end single-phase power tools up to 2000 kW watt. Designers can use this EVB to implement FOC designs for three-phase AC motors.
The main part of this EVM is a general-purpose, well-evaluated dense design consisting of a three-phase inverter bridge based on a 600-volt IGBT smart power module in an SDIP 25L package, mounted on a heat sink. This smart power module integrates all power IGBT switches with freewheeling diodes and high voltage gate drivers. This level of integration saves PCB space and assembly costs, and helps improve reliability. The board is designed to be compatible with single-phase power supplies from 90 to 285 volts AC and is also compatible with 125 to 400 volts of DC input.
