Inspection technology of automobile wiring harness assembly process and production process
Based on the messy layout of the existing engine wiring harness, the wiring direction cannot be distinguished during the maintenance process, the dressing is simple, easy to wear, and the waterproof performance is poor. Relevant builders have developed a low-voltage power control wiring harness assembly for electric vehicles.
This engine wiring harness assembly mainly includes: a wiring harness and a waterproof EFI system connector connected to the wiring harness, an OBD diagnostic connector, a waterproof body interface connector, a waterproof advance sensor connector, a waterproof oil-water separator connector, Waterproof advancer control valve connector, waterproof speed sensor connector, waterproof oil stop solenoid valve connector, accelerator sensor connector, waterproof water temperature sensor connector, wherein the OBD diagnostic connector of the engine wiring harness assembly is installed in the engine compartment, and Each connector and the wire harness are connected in a T-shape through wires. In this way, the T-shaped connections on the wire harness are respectively sleeved with three-way bushings, thereby achieving the goal of clamping and fixing the three-way bushings.
