Original Part Number: 968221-1
LHE Part Number: 6206420004
Contact Tab Size Series: 0.64
Size (MM): L:13.8 W:1.8 H:2.2
Wire Range(mm²): 0.3-0.5
Material: QSN6.5-0.1
Thickness (MM): 0.2
Seal or Unseal: Unseal
Overview:
| LHE PN: | 6206420004 |
| Certification: | TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS |
| MOQ: | Most product not have MOQ, Small order can be accepted. |
| Sample service: | Free Samples |
| Delivery Time: | 3-5 Days |
| Quality Control | All goods will be 100% inspected before dispatched |
| Payment: | T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. |
| Shipment: | DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving. |
The iron powder core magnetic ring is composed of carbon-based ferromagnetic powder and resin carbon-based ferromagnetic powder, and the magnetic permeability is very low. There is an air gap between the magnetic powder and the insulating material, and the general magnetic permeability is between 20-100. It is precisely because the magnetic permeability of the iron powder core magnetic ring is very low that it is not easy to saturate under the condition of high differential mode current. Therefore, the iron powder core magnetic ring is often used to make differential mode inductors.
