Original Part Number: BX2051B
LHE Part Number: 6299922316
Contact Tab Size Series: BX
Size (MM): L:28.3 W:5.4 H:4.2
Wire Range(mm²): 1.0-2.0
Material: H65
Thickness (MM): 0.4
Seal or Unseal: Unseal
Overview:
| LHE PN: | 6299922316 |
| Certification: | TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS |
| MOQ: | Most product not have MOQ, Small order can be accepted. |
| Sample service: | Free Samples |
| Delivery Time: | 3-5 Days |
| Quality Control | All goods will be 100% inspected before dispatched |
| Payment: | T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. |
| Shipment: | DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving. |
Pin 1 pin CHRG: The charging status indication function of the TP4054 chip. During the charging process, the connected LED is on, and when fully charged, the connected LED is off;
Pin 2 pin GND: the reference ground of the TP4054 chip, which belongs to the common end of the circuit;
Pin 3: BAT: the charging output of the TP4054 chip, directly connected to the positive pole of a single-cell lithium battery;
Pin 4 VCC: The power input terminal of the TP4054 chip is also the charging input interface of the single-cell lithium battery. The voltage working range is 4.5V~6.5V, which just meets the charger output voltage of 5V/1A and 5V/2A specifications
