Original Part Number: DJ622-2A
LHE Part Number: 6223021104
Contact Tab Size Series: 2.3
Size (MM): L:19 W:3.1 H:4.5
Wire Range(mm²): 0.5-0.75
Material: QSN6.5-0.1
Thickness (MM): 0.4
Seal or Unseal: Unseal
Overview:
| LHE PN: | 6223021104 |
| Certification: | TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS |
| MOQ: | Most product not have MOQ, Small order can be accepted. |
| Sample service: | Free Samples |
| Delivery Time: | 3-5 Days |
| Quality Control | All goods will be 100% inspected before dispatched |
| Payment: | T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. |
| Shipment: | DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving. |
How the sensor works
When the position of the Hall element is aligned between the teeth, the magnetic field lines of the permanent magnet pass through the Hall element and lead to the gear, and the magnetic field lines passing through the Hall element are dispersed in the two teeth, and the magnetic field is relatively weak. When the gear is aligned with the position of the Hall element, the magnetic field lines passing through the Hall element are concentrated on one tooth, and the magnetic field is relatively strong.
