Noise reduction measures for the intake system
The methods of dealing with gas flow noise and structure noise are relatively simple, and they are often not the main noise of the intake system. This paper mainly discusses the noise reduction measures of low frequency noise.
Reasonably design the air filter. Generally speaking, the larger the muffling volume, the better the muffling effect, but it is also necessary to comprehensively consider the layout space, the weight of the parts and the cost of the parts. Under normal circumstances, the volume of the air filter can reach more than 3 times the volume of the engine, and a good noise reduction effect can be achieved.
Determine the diameter and length of the inlet and outlet pipes of the air filter. Reducing the diameter of the inlet and outlet pipes of the air filter and increasing the expansion ratio is conducive to reducing noise, but it will increase the resistance of the intake system, reduce the intake air volume of the engine, and affect the performance of the engine. The effective muffling frequency of the air filter is related to the length of the trachea. If the length of the intake pipe is increased, the effective muffling frequency of the air filter will move to the low frequency. Therefore, it is also necessary to reasonably design the length of the inlet and outlet pipes.
