Original Part Number: DT06-3S-CE06
LHE Part Number: 201500311210BNEX
Number of Positions: 3
Contact Tab Size Series: C1.5
Size (MM): L:28.4 W:18.37 H:23.73
Seal or Unseal: Seal
Overview:
| LHE PN: | 201500311210BNEX |
| Certification: | TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS |
| MOQ: | Most product not have MOQ, Small order can be accepted. |
| Sample service: | Free Samples |
| Delivery Time: | 3-5 Days |
| Quality Control | All goods will be 100% inspected before dispatched |
| Payment: | T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. |
| Shipment: | DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving. |
With the development of new energy vehicles, the number of high-voltage wiring harnesses has gradually increased, and the main form of its terminals is closed terminals. The use of open terminals in wiring harnesses is relatively common, and the crimping method is relatively simple, so I will not do more analysis here. Today, we mainly analyze the closed terminal crimping and shielding ring crimping methods in high-voltage wiring harnesses. Shield ring crimping is a unique crimping type in high-voltage wiring harnesses, mainly for shielding connection, and the function will not be described in detail here. The main crimping methods of tube terminals are: 6-side crimping; 6-side 2-point crimping; MW-type crimping; 4-point crimping. Shield ring crimping methods mainly include: 6-side crimping; 6-side 2-point crimping; 6-point crimping.
