Original Part Number: IL-AG5-10S-S3C1
LHE Part Number: 208001020076
Number of Positions: 10
Contact Tab Size Series: 0.8
Size (MM): L:24.4 W:25.5 H:8.3
Seal or Unseal: Unseal
Overview:
| LHE PN: | 208001020076 |
| Certification: | TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS |
| MOQ: | Most product not have MOQ, Small order can be accepted. |
| Sample service: | Free Samples |
| Delivery Time: | 3-5 Days |
| Quality Control | All goods will be 100% inspected before dispatched |
| Payment: | T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. |
| Shipment: | DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving. |
If the faulty control module has a terminating resistor, it can be judged by the resistance measurement method. Measure the resistance between CAN H and CAN L of the diagnostic interface. If it becomes 120Ω, it means that there is an open circuit of the terminal resistance. If the faulty control module does not have a terminating resistor, it is necessary to measure the continuity of the CAN wire of the control module.
Replacing the control module involved in the fault code content can quickly determine whether the fault is caused by the control module itself. In addition, it is necessary to find breakpoints in combination with the network diagram, because corresponding bus hubs will be set up in the entire network. Different breakpoint locations will affect different components, and at the same time, it will also determine the control module that the diagnostic instrument can diagnose.
