IL-AG5-14S-D3C1 14 Ways Female Terminal Connector

Original Part Number: IL-AG5-14S-D3C1

LHE Part Number: 208001420077

Number of Positions: 14

Contact Tab Size Series: 0.8

Size (MM): L:24.4 W:25.8 H:13

Seal or Unseal: Unseal

Overview:

LHE PN: 208001420077
Certification: TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS
MOQ: Most product not have MOQ, Small order can be accepted.
Sample service: Free Samples
Delivery Time: 3-5 Days
Quality Control All goods will be 100% inspected before dispatched
Payment: T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery.
Shipment: DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving.

Enquiry Form

    Interesting Products

    name

    Company

    Email(*)

    Tel/Mobile

    Address

    Tell us your needs (as specific as possible)


    When the CAN L wire of a control module is disconnected, the control module cannot communicate, but the communication of other control modules still exists. The fault code of this faulty module may be read in other control modules. If there is an open circuit in the CAN L wire of several control modules, the communication function of these control modules will be affected.
    If the faulty control module has a terminating resistor, it can be judged by the resistance measurement method. Measure the resistance between CAN H and CAN L of the diagnostic interface. If it becomes 120Ω, it means that there is an open circuit of the terminal resistance. If the faulty control module does not have a terminating resistor, it is necessary to measure the continuity of the CAN wire of the control module.
