The inspection process is the last process of wire harness manufacturing error proofing, and it is also the last process to ensure the quality of the wire harness and product qualification. Including 100% electrical continuity inspection, staple inspection, relay, fuse link performance inspection, full-scale appearance inspection, bolt torque verification inspection, etc. The error-proof design of the process documents of the inspection process is particularly important.
Design different inspection processes according to customer needs and project requirements, but 100% continuity inspection and 100% full-size appearance inspection are the inspection items that must be designed for each wiring harness product. If necessary, 200% full-size appearance inspection or multi-frequency design is designed. Sampling inspection; design the image detection station of fuse wire and relay in the fuse box, and check the correctness of the installation of the accessories of the fuse box twice; design the performance detection station of relay and fuse wire, and detect the reliable operation of relay and fuse sex. It is not necessary to design the performance testing station for relays and fuses. The HMES system is used to conduct code scanning and passing monitoring and omission passing testing for continuity testing, card testing, image testing, relay performance testing, and full-size appearance testing. , The next process alarm, can completely avoid the occurrence of missed inspection.
