Original Part Number: 1-967623-1
LHE Part Number: 228001520739
Number of Positions: 15
Contact Tab Size Series: 2.8
Size (MM): L:22.8 W:26 H:18
Seal or Unseal: Unseal
Overview:
| LHE PN: | 228001520739 |
| Certification: | TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS |
| MOQ: | Most product not have MOQ, Small order can be accepted. |
| Sample service: | Free Samples |
| Delivery Time: | 3-5 Days |
| Quality Control | All goods will be 100% inspected before dispatched |
| Payment: | T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. |
| Shipment: | DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving. |
An example of a capacitor combination. The capacitors used in this combination are: 2 680uF tantalum capacitors, 7 2.2uF ceramic capacitors (0805 package), 13 0.22uF ceramic capacitors (0603 package), 26 0.022uF ceramic capacitors (0402 package). In the figure, the upper flat curve is the impedance curve of the 680uF capacitor, and the curves of the other three capacitances are the three V-shaped curves in the figure, which are 2.2uF, 0.22uF, and 0.022uF from left to right. The overall impedance curve is the thick envelope at the bottom of the figure.
