Original Part Number: MX23A34NF1
LHE Part Number: 310003421397
Number of Positions: 34
Contact Tab Size Series: 1.0
Size (MM): L:33.5 W:52 H:16.2
Seal or Unseal: Unseal
Overview:
| LHE PN: | 310003421397 |
| Certification: | TUV, IATF16949, ISO14001, ISO9001, CQC, UL, ROHS |
| MOQ: | Most product not have MOQ, Small order can be accepted. |
| Sample service: | Free Samples |
| Delivery Time: | 3-5 Days |
| Quality Control | All goods will be 100% inspected before dispatched |
| Payment: | T/T, Western Union, MoneyGram, PayPal; 30% deposits; 70% balance before delivery. |
| Shipment: | DHL/FedEx/TNT/UPS/EMS/Aramex/SF for samples, By Air or by Sea for batch goods; Airport/ Port receiving. |
Power MOSFET transistor, mainly responsible for 3.3V output. The maximum allowable current is 45A. Only the low-side power supply will use the 3.3V regulator shared with 5V.
Power Schottky rectifier, which is composed of two diodes. It allows up to 8A of current per diode (16A in total). This kind of power Schottky rectifier is usually used for 12V output.
A maximum of 60A current can be allowed to pass through. This power rectifier is commonly used for +5 V and +3.3 V outputs. Because the +5 V and +3.3 V outputs use the same rectifier, their sum cannot exceed the current limit of the rectifier.
